EAN:
SKU: PSP100Pro (B0179) 12V 24V on-board circuit detector circuit analysis intelligent diagnosis leakage detection, nozzle detection and cleaning parts activation relay detection wave scope, low voltage multimeter test, relay test 9-30V vehicle electrical system test
product description
Product material: ABS +
Product size: 210x70x30mm
Commodity weight: 1,100 g
Color selection: green / Black / red
Function:
Intelligent identification of voltage/resistance
Multimeter mode (measure voltage, resistance, diode, continuity )
Oscilloscope function
Activation of vehicle components
0-5V adjustable power supply
frequency
Network online free upgrade
Built in multiple languages
Over temperature protection: built-in temperature sensor, the high temperature equipment circuit breaker automatically closed
Overcurrent protection: when the working current exceeds 18A, the high equipment circuit breaker automatically closes
Software update: Support for USB port upgrade
Languages:
English, Spanish, German, French, Italian, Portuguese, Polish, Russian, Vietnam, Thai, Indonesian, Filipino, Malay, Arabic, Korean, Japanese, Traditional Chinese, Simplified Chinese
Specification parameters:
Display device: 2.4in TFT True color display screen
Resolution: 320 * 240 DPI
Operating temperature: 0-60°C (32-140F°)
Storage temperature: 40-70°C (-40-185F°)
External power supply: 12V-24V
Operating voltage: 9V-30V
Oscilloscope: 10Hz-200Hz
Measuring voltage: 0-100V
Measured voltage: 0.1V
Resistance measurement: 1-200K ohms
Current measurement: 0-18A
Continuous current: 18A
LED function: F8 high dual lamp
Package includes:
1pc x P100 Pro Main Unit
1pc x Extension Connection Line
1pc x Alligator Battery Clip
1pc x Solid Copper Test Probe Tip
1pc x Flexible Probe Cable
1pc x USB Cable
1pc x User Manual
1pc x Packaging Box
Product certification: CE, FCC, ROHS, UKCA
Packaging information
Product volume: 18.2*25*8.2cm
Package size: 18.2*25*8.2cm
Product weight: 1.5kg
Box size: 51.5 * 35 * 39cm
Quantity quantity: 16 pcs
Box weight: 20.2kg
Box weight: 20.2kg
